Display
Panel Size: 75"
Panel Type: TFT LCD Module with DLED Backlight.
Display Area (mm): 1649.644(H) x 927.936(V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ)
Contrast Ratio: 1200:1 Typ. , 4000:1 Max.(DCR enable)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hrs (typ)
Surface Treatment: Hardness: 9H. Anti-glare coating
Orientation: Landscape
Platform
Processor: ARM Cortex A73*4
RAM: 4GB
Storage: 32 GB
Touch
Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 33 points touch, Android: 20 points touch
INPUT
HDMI: 2.0 x4 ( 3840x2160 @60Hz ,HDCP2.2, HDMI2 with CEC/ARC )
RGB / VGA: x1 (1920x1080 @60Hz)
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1
WiFi: WiFi module slot x 1
OUTPUT
HDMI: x1(3840x2160@60Hz)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)
LAN
RJ45: x1
USB
Type A: USB2.0 x 3 (Front x2, Side x1 )
USB3.0 x 2 (Side x 2 )
Type B: x3(Front x1, Rear x 2)), for touch
Type C: x1 (USB2.0, DP1.2, Ethernet, PD 65W)
SPEAKERS
15W x 2 front soundbar + 15W x 1 subwoofer
MICROPHONE
built-in 8-array microphone
Top Camera Plate
Yes
Embedded OS
9.0
Bundle Software
Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: ViewBoard Cast & myViewBoard Display
Special Features
All-in-one USB port: USB 3.0 x 2
Simple LAN sharing between IFP and slot-in device: 10/100/1000M for Android and PC
Light Sensor: Yes
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 129.5W(typ.) / Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 800 x 400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH Non-Condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1709 x 1071 x 120 mm / 67.3 x 42.2 x 4.7 in
Packaging (inch / mm): 1848 x 1190 x 270 mm /72.7 x 46.8 x 10.6 in
WEIGHT
Net (lb / kg): 121.81lb/55.25kg
Gross (lb / kg): 170.81lb/77.48kg
REGULATIONS
cTUVus, FCC/ICES003, Energy star 8.0, Mexico CoC, Mexico Energy, EMC/CE, CB/LVD, EAC, UkrSEPRO, LBL, FF, Green BOM, RoHS, SCIP, WEEE , EPEAT, BSMI, ErP, REACH , TPCH, CA65, PAIA
PACKAGE CONTENTS
1.Power cable 2. Remote control 3. USB Type-C cable 4. USB Touch cable 5. Touch pen x 2 6. Quick Start Guide + Compliance statement 7. RS232 adapter 8. Clamp x 5 9. Camera Plate 10. Screw x 8 11. HDMI cable 12. Eraser 13. AAA Battery x 2
Compatible Slot-in PC
VPC12 & VPC25/27-O & VPC25/27-O-B series
