Display
Panel Size: 86"
Panel Type: TFT LCD Module with DLED Backlight
Display Area (mm): 1895.04(H) x 1065.96(V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ)
Contrast Ratio: 1100:1 Typ. , 2500:1 Max.(DCR enable)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hrs (typ)
Surface Treatment: Hardness: 9H. Anti-glare coating
Orientation: Landscape
Platform
Processor: ARM Cortex A73*4
RAM: 4GB DDR4
Storage: 32GB
Touch
Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 33 points touch, Android: 20 points touch
INPUT
HDMI: 2.0 x4 ( 3840x2160 @60Hz ,HDCP2.2, HDMI2 with CEC/ARC )
RGB / VGA: x1 (1920x1080 @60Hz)
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1
WiFi: WiFi module slot x 1
OUTPUT
HDMI: x1 (3840x2160 @60HZ)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)
LAN
RJ45: x1
USB
Type A: USB2.0 x 3 (Front x2, Side x1 )
USB3.0 x 2 (Side x 2 )
Type B: x3(Front x1, Rear x 2)), for touch
Type C: x1 (USB2.0, DP1.2, Ethernet, PD 65W)
SPEAKERS
15W x 2 front soundbar + 15W x 1 subwoofer
MICROPHONE
built-in 8-array microphone
Top Camera Plate
YES
Embedded OS
Android 9
Bundle Software
Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: ViewBoard Cast & myViewBoard Display
Special Features
All-in-one USB port: USB 3.0 x 2
Simple LAN sharing between IFP and slot-in device: 10/100/1000M for Android and PC
Light Sensor: Yes
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 150.4 W (typ.) / Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 800 x 600
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1957 x 1211 x 120 mm / 77 x 47.7 x 4.7 in
Packaging (inch / mm): 2102 x 1330 x 270 mm /82.7 x 52.3 x 10.6 in
WEIGHT
Net (lb / kg): 151.35lb/68.65kg
Gross (lb / kg): 179.46lb/81.40kg
REGULATIONS
cTUVus, FCC/ICES003, Energy star 8.0, Mexico CoC, Mexico Energy, EMC/CE, CB/LVD, EAC, UkrSEPRO, LBL, FF, Green BOM, RoHS, SCIP, WEEE , EPEAT, BSMI, ErP, REACH , TPCH, CA65, PAIA
PACKAGE CONTENTS
1. Power cable (3 meters) 2. Remote control 3. USB Type-C cable (1.5 meters) 4. USB Touch cable (3 meters, USB2.0) 5. Touch pen x 2 6. Quick Start Guide + Compliance statement 7. RS232 adapter 8. Clamp x 5 9. Camera Plate 10. Screw x 8 (camera 2+2, wall mount 4) 11. HDMI cable (3 meters) 12. Eraser 13. AAA Battery x 2
Compatible Slot-in PC
VPC12 & VPC25/27-O & VPC25/27-O-B series
Note
Disclaimer:
1.Although we endeavor to present the most accurate and comprehensive information at the time of publication, we reserve the right to make any change regarding any info herein without prior notice. 2.Unless otherwise stated, all performance claims are based on theoretical performance. Actual figures may vary in real-world situations and may depend on many factors including the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment. 3.Product Specification and appearance may differ from country to country and from model to model. We recommend that you check with your local dealers for the specification and the appearance of the product model available in your country. Colors of products may not be perfectly accurate due to variations caused by photography and monitor settings.
