Display
Panel Size: 75"
Panel Type: TFT LCD Module with DLED Backlight
Display Area (mm): 1649.644(H) x 927.936(V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1 Typ. , 5000:1 Max.(DCR enable)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 Hours (Typ.)
Surface Treatment: Hardness: 9H with Anti-Fingerprint coating & Anti-Glare coating
Platform
Processor: ARM Cortex A73*4
RAM: 8GB
Storage: 64GB
Touch
Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 33 points touch, Android: 20 points touch
INPUT
HDMI: x2 (3840x2160@60Hz, HDCP2.2, CEC, Front x1, Side x1), x1 (3840x2160@60Hz, HDCP2.2, CEC, ARC, Side x 1)
RGB / VGA: x1 (1920x1080 @60Hz)
DisplayPort: x1 (3840x2160 @60Hz)
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1
WiFi: module slot x 1
OUTPUT
HDMI: x1 (on demand)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)
LAN
RJ45: x1
USB
Type A: USB 2.0 x1(Side x1), USB 3.0 x4 (Front x2, Side x2, SmartPort™ USB)
Type B: x2, for touch
Type C: x1 (USB3.0, DP1.2 Alt Mode, 100M Ethernet, 60W PD)
SPEAKERS
20W x 2 + 40W x 1 subwoofer
MICROPHONE
built-in 8-array microphone
Top Camera Plate
Yes
Embedded OS
Android 9
Bundle Software
Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: ViewBoard Cast & myViewBoard Display
Special Features
All-in-one USB port: USB 3.0 x 4
Simple LAN sharing between IFP and slot-in device: 10/100/1000M for Android and PC
Light Sensor: Yes
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: On: 149.97W(typ.) / Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 800 x 400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH Non-Condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1720.1 (W) x 1069.6 (H) x 118.4 (D) mm, 67.72 (W) x 42.11 (H) x 4.66 (D) inch
Packaging (inch / mm): 1880 (W) x 1160 (H) x 280 (D) mm, 74.02 (W) x 45.67 (H) x 11.02 (D) inch
WEIGHT
Net (lb / kg): 125.22 lb / 56.8 kg
Gross (lb / kg): 158.95 lb / 72.1 kg
REGULATIONS
EMC/CE, CB, RoHS & DOC, REACH, WEEE, ErP. EEI
PACKAGE CONTENTS
1. Power cable(3 meters) 2. Remote control 3. USB Type-C cable (1.5 meters) 4. USB Touch cable (3 meters, USB2.0) 5. Touch pen x 2 6. Quick Start Guide + Compliance statement 7. RS232 adapter 8. Clamp x 5 9. Camera Plate 10. Screw x 8 (camera 2+2, wall mount 4) 11. HDMI cable (3 meters) 12. Eraser 13. 13. AAA Battery x 2
Compatible Slot-in PC
VPC12-WPO/VPC2C-O/VPC25-O/VPC27-O series
