Specyfikacja techniczna:

• SPECIFICATION

  Panel Size: 10" (10.1'' diagonal)

  Type/ Tech: TFT LCD Module with LED Backlight

  Display Area (mm): 216.96(W) x 135.6(H)

  Aspect Ratio: 16:10

  Resolution: 1280 x 800

  Colors: 262K Color

  Brightness: 300 nits (typ.)

  Contrast Ratio: 800:1 (typ.)

  Response Time: 25 ms

  Viewing Angles: Top = 85, Bottom = 85, Left = 85, Right = 85 (typ.)

  Backlight: LED

  Backlight Life: 10,000 Hours (typ.)

• TOUCH

  Type/ Tech: Capacitive

  Touch Resolution: 1280x800

  Touch Point: 10 point for gesture

• INPUT

  Audio: x1 (3.5mm jack)

  SD/SDHC: Micro SD (Up to 32GB)

• LAN

  RJ45: x1 (10M/100M BASE-T, PoE 13W)

• USB

  Type A: x2 (USB2.0)

  Micro USB: x1

• CAMERA

  2M Pixel

• SPEAKERS

  2W x2

• BUILT IN PLAYER

  OS: Android 4.4

  Processor: Rockchip RK3188

  Storage: 1GB DDR3-1600 SDRAM

  Graphic: ARM Mali400 MP4

  Storage: 8GB

  HDMI (1080p): Up to 1080p @ 50/60Hz

• POWER

  Voltage: 100-240VAC +/- 10% Wide Range

  Consumption: 13.5W (Max)

• ERGONOMICS

  Tilt: N/A

  Wall Mount (VESA® ): 75 x 75mm

• OPERATING CONDITIONS

  Temperature (º C): 32°F to 104°F (0°C to 40°C)

  Humidity: 30% ~ 80% non-condensing

• DIMENSIONS (W X H X D)

  Physical (inch / mm): 269.88 x 170 x 28.5 mm / 10.62 x 6.69 x 1.12 in.

  Packaging (inch / mm): 336 x 100 x 227 mm / 13.2 x 3.93 x 8.93 in.

• WEIGHT

  Net (lb / kg): 0.727 kgs / 1.6 lbs

  Gross (lb / kg): 2.245 kgs / 4.95 lbs

• REGULATIONS

  Standard: FCC, cTUVus, Mexico COC, ICES-003

• WHAT'S IN THE BOX?

  1. AC Adapter

  2. Power plug x 1 (US/EU/AU/UK)

  3. Power and Micro SD card brackets

  4. Display stand

  5. Hardware Quick Start Guide

  6. Software Quick Start Guide

  7. Documentation CD (UG, QSG, Signage Manager software)

  *Actual content may differ from market to market
