Display
Panel Size: 65"
Panel Type: TFT LCD Module with DLED Backlight.
Display Area (mm): 1428.48(H)x 803.52 (V) (64.5" diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colours: 1.07B colours (8bit+FRC)
Brightness: 400 nits (typ.)
Contrast Ratio: 4000:1
Response Time: 6.5ms
Viewing Angles: H=178, V=178typ.
Backlight Life: 50,000 Hours (Min)
Surface Treatment: Hardness: 9H Anti-glare coating
Orientation: Landscape
Platform
Processor: ARM quad-core Cortex-A55
RAM: 4GB DDR4
Storage: 32 GB
Touch
Type/ Tech: Ultra Fine Touch Technology
Touch Point: 20 points touch, 2 points writing
INPUT
HDMI: HDMI 2.0 x2 (3840x2160 @60Hz)
RGB / VGA: x1
Audio: x1
RS232: x1
OPS: x1 (Optional Intel Standard OPS)
WiFi: x1
OUTPUT
Audio: x1
LAN
RJ45: x1
USB
Type A: USB2.0 Front x2; Side x2
Type B: x1 for HDMI/VGA touch
SPEAKERS
12W x 2
Top Camera Plate
Yes
Embedded OS
Android 9
Bundle Software
Basic Annotation Software: myViewBoard Whiteboard
Pro Annotation Software: myViewBoard Whiteboard for Windows (Embedded in optional Windows Slot-in PC)
Wireless Presentation: myViewBoard Display & ViewBoard Cast​
Special Features
All-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front "SmartPort™ USB" to all channels.
Simple LAN sharing between IFP and slot-in device: 10/100M for Android & Slot-in PC
Light Sensor: Yes
Power
Voltage: 162V-264V +/- 10%
Consumption: On: 175W(typ.)
Off: ≤ 0.5W\
ERGONOMICS
Wall Mount (VESA® ): 600*400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1489×897×87 mm / 58.6x35.3x3.4 in
Packaging (inch / mm): 1628×208×1005 mm / 64x8.2x39.5 in
WEIGHT
Net (lb / kg): 38.3kg/84.4lb
Gross (lb / kg): 46.0kg/101.4lb
REGULATIONS
EMC/CE , CB/LVD, GOST-R / EAC, FAC, RCM, BIS, ECAS, LBL (Low Blue Light Certification), RoHS, REACH, SCIP, WEEE, TPCH, Packing waste, CA65, Green BOM, ErP-Eco
PACKAGE CONTENTS
1. Power cord / 2.Remote control with AAA battery / 3.USB touch cable / 4. Touch pen x 2 / 5. Quick Start Guide + Compliance statement / 6. RS232 adaptor / 7. Screw x 4 ( wall mount 4) / 8. HDMI cable / 9. Clamp x5 / 10. Camera plate x1
Compatible Slot-in PC
VPC12-WPO/VPC25/VPC27 series
