SPECIFICATIONS

Display
Panel Size: 65"
Panel Type: TFT LCD Module with DLED Backlight
Display Area (mm): 1428.48(H) x 803.52 (V) (64.5" diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 350 nits (typ.)
Contrast Ratio: 4000:1
Response Time: 6.5ms
Viewing Angles: H = 178, V = 178 typ.
Surface Treatment: Hardness: 7H (9H pencil), Anti-flare coating
Orientation: Landscape
Platform
Processor: ARM quad-core Cortex-A55
RAM: 2GB DDR4
Storage: 16GB
Touch
Type/ Tech: Ultra Fine Touch Technology
Touch Point: 20 points touch, 2 points writing
INPUT
HDMI: 2.0 x2 (3840x2160 @60Hz)(HDMI2 port support ARC function)
RGB / VGA: x1
Audio: x1 (PC audio in)
RS232: x1
OPS: OPS slot x1 (compatible with Intel standard OPS)
WiFi: WiFi slot x1 (compatible with VB-WIFI-002)
OUTPUT
Audio: x1 (Earphone out)
LAN
RJ45: x1
USB
Type A: USB2.0 Front x2 (SmartPort™ USB);Rear x2
Type B: x1 for HDMI/VGA touch
SPEAKERS
10W x 2
Top Camera Plate
Yes
Embedded OS
Android 9
Bundle Software
Basic Annotation Software: myViewBoard Whiteboard
Pro Annotation Software: myViewBoard Whiteboard for Windows(Embedded in optional Windows Slot-in PC)
Wireless Presentation: myViewBoard Display
Special Features
All-in-one USB port (combine Windows/Android USB port; no need to distinguish them anymore): (combine slot-in PC/Android/HDMI USB port) Front "SmartPort™ USB" to all channels.
Simple LAN sharing between IFP and slot-in device: 10/100M for Android & Slot-in PC
Light Sensor: Yes
Power
Voltage: 162-240VAC +/- 10%
Consumption: Off: <0.5W
ERGONOMICS
Wall Mount (VESA® ): 600x400
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1489×897×87 mm / 58.6x35.3x3.4 in
Packaging (inch / mm): 1628×208×1005 mm / 64x8.2x39.5 in
WEIGHT
Net (lb / kg): 38.3kg/84.4lb
Gross (lb / kg): 46.0kg/101.4lb
REGULATIONS
BIS, CB, CE
PACKAGE CONTENTS
1. Power cable (3 meters) / 2. Remote control / 3. USB cable (3 meters) / 4. Touch pen x 2 / 5. Quick start guide / 6. RS232 adapter / 7. Clamp x 5 / 8. Webcam plate / 9. Screw x 8 / 10. HDMI cable (3 meters)
Compatible Slot-in PC
VPC12-WPO
