SPECIFICATIONS

• LCD PANEL

  Panel Size : 55" (54.64")

  Type/ Tech : TFT LCD Module with LED Backlight

  Display Area (mm) : 1209.6 x 680.4 mm

  Aspect Ratio : 16:09

  Resolution : 1920x1080

  Colors : 1.06 billion colors

  Brightness : 500 nits

  Contrast Ratio : 1400:1 Typ.

  Response Time : 12 ms

  Viewing Angles : 178° / 178°

  Backlight : LED Backlight

  Backlight Life : 60,000 Hours Typ

  Hardness : Hard coating (3H), Anti-glare treatment

• INPUT

  HDMI : x2 (1.4a)

  RGB / VGA : x1

  DisplayPort : x1 (1.2)

  DVI : x1

  Audio : x1 (RCA connector)

  CVBS : x1 (shared with component Y)

  YPbPr : x1

  RS232 : x1

  IR Pass Through : x1

  OPS : x1

• OUTPUT

  DisplayPort : x1 (1.2)

  DVI : x1

  Audio : x1

  RS232 : x1

  IR Pass Through : x1

• LAN

  RJ45 : x1

• USB

  Type A : x1 (2.0)

• SPEAKERS

  10W x2

• COMPATIBILITY

  RGB PC/HDMI PC : Up to 1920x1080 @60Hz. Refer to timing table

  CVBS : 480i

  YPbPr : 480i, 480p,720p,1080i,1080p

  DisplayPort : 480i, 480p,720p,1080i,1080p, 4k2k@30Hz

  HDMI : 480i, 480p,720p,1080i,1080p, 4k2k@30Hz

  DVI : 480i, 480p,720p,1080i,1080p

• CONTROLS

  Physical- Top OSD : POWER, MUTE, INPUT, VOL -/+, UP, DOWN, MENU

  Picture style, Restore style, Backlight, Colour, Sharpness, Noise reduction, MPEG artifact reduction, Digital Crystal Clear, Advanced, Game or computer, Format and edges, Input resolution

  Sound style, Restore style, Bass, Treble, Balance, Surround mode, Audio Out, Advanced

  Enable, H monitors, V monitors, Position, Frame Comp.

  Menu language, Monitor ID, Eco mode, Auto search, Clock, Scheduling, Sleep timer, CEC, Auto adjust, Locak KB lock, RC lock, Pixel shift, Smart power, Wake on lan, Switch on state, Light sensor, LED, Switch on delay, Logo, APM, Information OSD, DisplayPort Ver., Cooling fan, Network control port,Factory settings.

  View network settings, Network configuration, Static IP Configuration, Digital Media Renderer-DMR, Network name

  Embedded Linux OS : N/A

  Multimedia : N/A

• POWER

  Voltage : 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz

  Consumption : "On" 185W(typ)

  "Power Saving" < 0.5 W

  "Off" (Suspend) < 0.5 W

• ERGONOMICS

  Tilt : N/A

  Wall Mount (VESA® ) : 400 x 400 mm

• OPERATING CONDITIONS

  Temperature (º C) : 5- 40°C (landscape)

  5- 35°C (portrait)

  Humidity : 20% ~ 80% non-condensing

• DIMENSIONS

  Physical (inch / Mm) : 1213.4 x 684.2 x 95.0 mm (w/o Stand)

  1213.4 x 726.2 x 400 mm (with Stand)

  Packaging (inch / Mm) : 1551 x 961 x 450 mm

• WEIGHT

  Net (lb / Kg) : 29.2 kg (w/o stand)

  31.5 kg (with stand)

  Gross (lb / Kg) : 43.4kg

• REGULATIONS

  Standard : CE, CB, WEEE, C-tick, FCC, ICES003, UL/cUL, CE,CB, CU, Energy star 6.0,RoHS, ErP, REACH, PSB, RCM, SASO, EPEAT, UL-MX-CoC,CONUEE

• WHAT'S IN THE BOX?

  1. CDX5552 LCD Monitor

  2. Remote Control with batteries

  3. User manual CD wizard

  4. Quick Start Guide

  5. Power Cables

  6. VGA cable

  7. RS232 cable

  8. IR sensor cable

  *Actual content may differ from market to market
